The SG560 and 560V is New for 2010 with improved
circuitry and more memory capacity - up to 8GB! The
560V includes a color 1.7" LCD screen for viewing images
in the field.
•Image Sensor - 5MP Color CMOS Sensor
•Maximum Resolution - 2560x1920
•Lens - F=3.1mm
•FOV - (Field of View)=40°
•Auto IR-Cut-Remove (Night)
•IR-Flash 45Ft
•Remote Control Display - 1.7inches LCD Color
•Display/Viewer(SG560V only)
•External capacity - SD Card from 8MB to 8GB
•Picture Resolution 5MP = 2560x1920 3MP = 2048x1536
•Video Resolution = 640x480(Default, 16FPS) 320x240
(20FPS)
•PIR Lens - Multi Zone
•PIR sensitivity Adjustable(High/Normal/Low)
•IR Bulbs - 24 Long Range IR Emitters
•Operation - Day/Night(24hours)
•Trigger Time - 1.2s
•Interval = 1s – 60m Programmable
•Capture Mode - 1-3 Programmable
•Video Length = 1-60s Programmable
•Power Supply - 8xAA or 4xAA (6V DC)
•Stand-by Current = < 0.3mA(<7mAh/Day)
•Power Consumption - 150mA (+450mA When IR-LED
Lighted)
•Low Battery Alert - Blue LED Indicator
•User Interface - Remote Control With LCD Display
(SG560V only)
•Ports & Jacks - Rem ote Control Jack/ USB Jack, TV Out
Jack, SD Card Slot, 6V DC Jack
•Mounting Strap
•Cable Lock Up To 3/8 Inches
Dimensions:
•Height: 5-1/2 inches
•Width: 4 inches
•Depth: 2-1/2 inches
•Weight: Approximate 1 lb With Battery
•Operation Temperature: -4F to 140F
•Storage Temperature: -22F to 158F
•Operation Humidity: 5% - 90%
•Security Authentication - FCC CE RoHS
Applications:
Hunters - Trails, Food Plots, Feeders, Property
Surveillance and Observation
Home, Office and Community - Indoor and Outdoor
Surveillance
Law Enforcement and Environmental Agencies - Illegal
Dumping, Vandalism and Theft
University Research and Studies - Wildlife Observation
and Research
circuitry and more memory capacity - up to 8GB! The
560V includes a color 1.7" LCD screen for viewing images
in the field.
•Image Sensor - 5MP Color CMOS Sensor
•Maximum Resolution - 2560x1920
•Lens - F=3.1mm
•FOV - (Field of View)=40°
•Auto IR-Cut-Remove (Night)
•IR-Flash 45Ft
•Remote Control Display - 1.7inches LCD Color
•Display/Viewer(SG560V only)
•External capacity - SD Card from 8MB to 8GB
•Picture Resolution 5MP = 2560x1920 3MP = 2048x1536
•Video Resolution = 640x480(Default, 16FPS) 320x240
(20FPS)
•PIR Lens - Multi Zone
•PIR sensitivity Adjustable(High/Normal/Low)
•IR Bulbs - 24 Long Range IR Emitters
•Operation - Day/Night(24hours)
•Trigger Time - 1.2s
•Interval = 1s – 60m Programmable
•Capture Mode - 1-3 Programmable
•Video Length = 1-60s Programmable
•Power Supply - 8xAA or 4xAA (6V DC)
•Stand-by Current = < 0.3mA(<7mAh/Day)
•Power Consumption - 150mA (+450mA When IR-LED
Lighted)
•Low Battery Alert - Blue LED Indicator
•User Interface - Remote Control With LCD Display
(SG560V only)
•Ports & Jacks - Rem ote Control Jack/ USB Jack, TV Out
Jack, SD Card Slot, 6V DC Jack
•Mounting Strap
•Cable Lock Up To 3/8 Inches
Dimensions:
•Height: 5-1/2 inches
•Width: 4 inches
•Depth: 2-1/2 inches
•Weight: Approximate 1 lb With Battery
•Operation Temperature: -4F to 140F
•Storage Temperature: -22F to 158F
•Operation Humidity: 5% - 90%
•Security Authentication - FCC CE RoHS
Applications:
Hunters - Trails, Food Plots, Feeders, Property
Surveillance and Observation
Home, Office and Community - Indoor and Outdoor
Surveillance
Law Enforcement and Environmental Agencies - Illegal
Dumping, Vandalism and Theft
University Research and Studies - Wildlife Observation
and Research
| SG560 and SG506V |
